control panel transformers

control panel transformer

voltages			VA rating	dimensions					%	inrush VA	weight
			part no.	A	B	C	D	E	reg	for 10%	kg
Primary	0-220-230-240	U	CL50	76	70	86	53	47	9	105	1.1
	0-380-400-415	N	CL75	76	76	86	53	53	8.8	160	1.5
Secondary	0-12	J	CL100	84	78	95	60	68	6.7	250	2.2
	0-24	B	CL150	96	76	102	68	63	6.7	375§	3.2
	0-48	E	CL200	96	86	102	68	73	5.8	550	4.0
	0-110	F	CL250	96	101	102	68	88	5.3	720	5.0
	0-230	U	CL300	120	88	122	80	71	5.3	870	6.0
			CL500	120	120	122	80	103	4.1	1700	7.5
			CL750	150	135	140	105	70	5.2	2200	10.0
			CL1000	150	161	140	105	96	3.3	400	13.0
			CL1500	150	188	140	105	123	3.2	6200	16.0
			CL2000	175	150	165	153	125	3.3	8060	18.0
			CL2500	175	178	165	153	158	2.6	12100	20.0
